ACON Mission U120 Smart Urine Analyzer_

ACON Mission U120 Smart Urine Analyzer_

Technical Specification of Acon Mission U120 Smart Urine Analyzer:

Product Name ACON Mission U120 Smart Urine Analyzer
Brand Acon
Model Mission U120
Type Urine Analyzer
Methodology Reflectance Photometry
Detection Photosensitive Diode
Throughput Single Test Option: 60 tests/hour
Continuous Test Option: 120 tests/hour
Test Categories Routine, STAT, and QC
Memory Last 2,000 results
Strip Incubation Time 1 Minute
Wavelength of Monochromatic LED 525 nm and 635 nm
Strips Available 1-11 parameters (108 x 5 mm); see URS Parameters
Total Combinations Per Analyzer 15 Combinations
Analyzer Ports
  • RS232C Port for Barcode Reader or Data Transfer
  • USB Port for Data Transfer
  • 25 Pin Parallel Port for External Printer
Data Entry Capabilities Operator/Patient ID – Manual Entry and Barcode Reader (Up to 20 characters)
Connection Capabilities
  • USB or RS232C Data Transfer Cable (optional)
  • RS232C Barcode Reader (optional)
  • Optional External Printer (not included)
Major Readable Barcodes
  • Code 128
  • Code 39
  • Codabar (NW-7)
  • EAN 8
  • EAN 13
  • Interleave 25
  • UPCA
  • UPCE
Calibration Automatic
Languages English, French, German, Italian, Portuguese and Spanish
Operating Conditions 0-40°C (32-104° F); < 85% RH
Storage Conditions  -5-50°C (23-122° F); < 90% RH
Power Source 100-240 VAC, 50-60 Hz
Dimensions 27.2 x 26.9 x 14.6 cm (10.7″ x 10.6″ x 5.7″)
Display Dimensions 10.8 x 5.7 cm (4.2″ x 2.2″)
Weight 2.6 kg (5.7 lbs) without batteries or power supply
What’s In The Box?
  • Main Unit
  • 1 Strip Holder
  • 2 Printer Paper Rolls
  • 2 Fuses (2.0A)
  • 1 Power Cord
  • 1 Quick Start Guide
  • 1 Instruction Manual

ACON Mission U120 Smart Urine Analyzer : Specifications

Product Condition
Brand New
Estimated Delivery
3-7Days
Warranty
  • 1 Year ,
  • From Manufacturer
Brand/Manufacturer
Brand
Acon
Product General Specifications
Product Name
ACON Mission U120 Smart Urine Analyzer
Product Model
Mission U120
Qty./BOX
1
Weight & Dimensions
Product Dimension (mm)
272 x 269 x 146
Product Weight
2.6Kg
Memory and Storage
Storage
2000 results
Lab Equipment Features
Wavelength Range (nm)
525-635
Throughput (Tests/Hour)
60-120

Original price was: ₹55,000.00.Current price is: ₹40,800.00.

Add to wishlist Add to compareAsk about product
Category:

Description

ACON Mission U120 Smart Urine Analyzer : Product description

The Mission U120 Smart Urine Analyzer is the perfect solution for efficient urine testing. With a capacity of up to 120 tests per hour, it saves time while producing accurate results. The analyzer also boasts a memory that can store up to 2,000 test results, making it easy to recall previous results for comparison. The analyzer is 510(k) Cleared and CLIA Waived, which means it is approved for use with Mission® Urinalysis Reagent Strips and Mission Urine Controls. And the best part? You can get all of these benefits at an affordable Mission U120 Urine Analyzer price.

Key Features of ACON Mission U120 Smart Urine Analyzer:

High Accuracy and Reliability

  • Automatic calibration before each test – No calibration strips required
  • Up to 120 test/hour in Continuous Mode
  • Over 15 combinations available for analyzer reading
  • Can read ALB/CRE strips

Easy Operation

  • Saves and recalls the last 2,000 results automatically
  • Robust construction
  • Clear on-screen instruction
  • QC Lockout function with QC tests reminders

Data Management

  • Includes RS232C and USB ports for data transfer to a computer and LIS
  • HL7 compliant
