Arkray Orinalyser U120 Urine Analyzer

Technical Specification of Arkray Orinalyser U120 Urine Analyzer:

Product Name	Arkray Orinalyser U120 Urine Analyzer
Brand	Arkray
Model	Orinalyser U120
Methodology	Reflectance Photometry
Detection	Photosensitive Diode
Test Methods	Routine, STAT, and QC
Memory	Last 2000 tests
Strip incubation time	1 minute
Wavelength	525 nm and 635 nm
Standard Strips	2 , 4 , 10 parameters (5mm x 108mm)
Throughput	60 tests/hours: single strip option 60 tests/hours: single strip option
Analyzer ports	Standard RS232C port for barcode reader or data transfer 25 pin parallel port for external printer
Printer	Inbuilt thermal printer and port for external printer
Major readable barcodes	Code 128, Code 39, Codabar (NW-7) Interleaved 25 UPC-A, UPC-E, EAN 8, EAN 13
Calibration	Automatic
Operating conditions	0 – 40° C (32 – 104° F); < 85% RH
Storage conditions	-5 – 50° C (23 – 122° F}; < 90% RH
Power source	100 – 240 VAC. 50 – 60 Hz
Dimensions (LxWxH)	32cm x 22cm x 18.6 cm
Display Dimensions	10.8cm x 5.7cm
Weight	2.6 Kg (5.73 lbs)

Arkray Orinalyser U120 Urine Analyzer : Specifications

Original price was: ₹83,000.00.Current price is: ₹51,400.00.

Add to wishlist Add to compareAsk about product

Category: Medical Equipments

Description
Reviews (0)

Description

Arkray Orinalyser U120 Urine Analyzer : Product description

Arkray Orinalyser U120 is a Urine Analyzer that used to perform automatic urine testing. The Orinalyser U120 Urine Analyser is a Single Strip Urine Reagent Strip Analyser. It is a reflectance photometer that analyzes the intensity and color of light reflected from the reagent areas of a urinalysis reagent strip.

Key Features of Arkray Orinalyser U120 Urine Analyzer:

Facility to use single strip as well as continuous strip option
60 tests/hour with single strip option and 120 tests/hour with continuous strip option
Auto flag for abnormal results
Beep signal to begin test
RS232C & USB port for data transfer
